MODEL Senographe DMR
X-RAY TUBE
Anode type (X-RAY TUBE) Rotating, air cooled
Heat capacity, hu (X-RAY TUBE) 90000
Heat dissipation rate, hu/min (X-RAY TUBE) 60000
Target/filter combinations (X-RAY TUBE) Mo/Mo, Mo/Rh, Rh/Rh
Focal spot size, mm (X-RAY TUBE) 0.1and 0.3
OPTIONAL ATTACHMENTS (SHOCK-WAVE GENERATOR) Phantom, needle guides, compression paddle, hydraulic chair, accessory rack, Stereotix 2
GENERATOR Single phase, high frequency
Kv range (X-RAY GENERATOR) 22increments of 1 kV
mAs RANGE (X-RAY TUBE) 4
Ma range (IMAGING SYSTEM) 40-100
Time range, sec (X-RAY TUBE) 0.035-20
Handswitch (OUTPUTS) Optional
SCREEN FILM CAPABILITIES (X-RAY TUBE) 5,user defined
RADIATION SHIELD (X-RAY TUBE) Yes
L x w, cm (in) (CONTROL CONSOLE) 201x 71 (79x 28)
Thickness (DIMENSIONS, cm (in)) 0.5mm Pb equivalent
Bucky (GENERAL RADIOGRAPHY) 18x 24 cm; 24x 30 cm optional
Grid ratio (IMAGING SYSTEM) 5:1, 30 lines/cm
FILM ID (X-RAY TUBE) Optional
COMPRESSION METHOD (X-RAY TUBE) Motorized, manual compression adjust; programmable speed, pressure, and automatic release
Force, newtons (X-RAY TUBE) 30-200
POWER NEEDED 200-415 VAC, 50/60 Hz
DIMENSIONS (HXWXD) CM, (IN) (DISPLAY) 171x 55 x 122 (67.2x 21.6 x 48)
WEIGHT, kg (lb) (DISPLAY) 280 (617),column
STEREOTACTIC UNIT (POSITIONING ASSEMBLY) Stereotix 2
POSITIONING ASSEMBLY
Collimation (POSITIONING ASSEMBLY) Automatic
18x 24 cm (POSITIONING ASSEMBLY) Yes
24x 30 cm (POSITIONING ASSEMBLY) Yes
Motion locks (POSITIONING ASSEMBLY) Electromagnetic
Assembly movement Rotation, ° (POSITIONING ASSEMBLY) ±180
Vertical axis, cm (in) (POSITIONING ASSEMBLY) 71.1(28)
Sid, cm (POSITIONING ASSEMBLY) 56-66
Scale guide (POSITIONING ASSEMBLY) Digital mm and pressure
MAGNIFICATION UNIT (X-RAY TUBE) 1.3x-1.9x
AEC DETECTOR (POSITIONING ASSEMBLY) Microprocessor-controlled PMT
Variable parameters (POSITIONING ASSEMBLY) mAs, kV, anode track, filter type, mAs in AOP and AEC
OTHER ATTRIBUTES (Interference compensation) Modular system; dual-track x-ray tube; software for calibration and maintenance; totally automatic mode (AOP) selects kV, track, and filter and terminates exposure at 40 msec if kV or backup mAs time is too low.
MARKETING REGION (Interference compensation) Worldwide
